| 1.Electrical Characteristics | |
| Rated voltage: | DC 5V |
| Rated current : | 1mA (Resistance loading) |
| Max. operating current: | 2.5mA (Resistance loading) |
| Resolution: | 16pulses/360° |
| Insulation resistance: | 10MΩ Min at DC 50V |
| Dielectric strength: | 1 minute at AC 50V |
| Channel: | 16 Channel |
| 2.Mechanical Characteristics | |
| Total ratational angle: | 360°(Endless) |
| Number and position of detent: | 16detents Step angle:22.5°±5° |
| Detent torque: | 5~35mN.m.(50~350gf.cm) |
| Shaft wobble: | 0.8*L/30mm p-p MAX |
| Push-Pull Strength of shaft | 8KG |
| 3.Endurance Characteristics | |
| Rotational life: | 30,000cycles |
| Operating temperature range: | -30ºC to+80ºC |
| Storage temperature range: | -40ºC to+85ºC |
